FAQ – Commuter Series Bikes

General Questions

How much does the bike weigh?


The total weight of the bike including the battery is 44 pounds.




Does the total weight include the battery?


Yes, the total weight of the bike including the battery is 44 pounds.




What is the weight capacity for the rear rack?


The rear rack is rated to carry 32 pounds. The maximum total weight including the rider is 235 pounds.




Does the bike come in other colors?


Both the CS-240 and CS-260 are available in the white with blue trim pattern. The CS-260 is also available in matte black with blue trim.




Does the bike come with a kickstand?


Yes, the bike comes equipped with an adjustable kickstand.




Is the handlebar adjustable?


Yes, the handlebar can be adjusted vertically to accommodate riders of different heights. The maximum handlebar height is 46” from the top of the handlebar to the ground. The lowest handlebar position is 38.5” from the top of the handlebar to the ground. The handlebar can also be rotated forward and backward to accommodate your preferred hand grip position.




Does the bike have shock absorbers?


Although the Commuter Series models do not have a front suspension fork, the ride is smooth and comfortable on the road.




Does the bike have front and rear lights or reflectors?


The bike comes equipped with front and rear reflectors, as well as high-visibility reflectors on each wheel for added safety.




What is the minimum height to ride this bike?


The lowest saddle position height is 29” from the top of the seat to the ground. The total inseam from the crotch to the ground should not be less than the 29” minimum stand-over height.




What is the maximum height to ride this bike?


The Commuter Series bikes support a wide range of rider sizes. Your total inseam from the crotch to the ground should not exceed the 42" maximum stand-over height. While the 20" wheels are perfectly compact for storage and transport, you should be advised that this bike is smaller than traditional full-sized bikes.




What is the size of the chainring?


The chainring is 9” in diameter.




Does the bike ship fully assembled?


The Commuter Series bikes ship 99% assembled. The only assembly required is the installation of the two pedals. The pedals can be fastened to the pedal cranks with a small adjustable wrench.




Should I take the bike to a bicycle mechanic for fine tuning?


Although not required, it is always a good idea to have a qualified bicycle mechanic confirm that the bike is in suitable condition for extended riding. For more information about bicycle maintenance and fine tuning please visit our website.




What is the maximum speed of the bike?


The maximum speed using the throttle is 15 miles per hour (24.14 Km/h). Faster speeds can be achieved using the pedal assist function in combination with swift pedaling.




Does the bike have a pedal-free mode?


Yes, the bike comes equipped with a thumb-paddle style throttle located beneath the display. Simply select your level of pedal assistance (PAS 1-5) and pedal once or twice to begin moving forward, then press the throttle forward and stop pedaling to use fully automatic mode.




What is the top speed using the throttle?


The maximum speed using the throttle is 15 miles per hour (24.14 Km/h). Faster speeds can be achieved using the pedal assist function in combination with swift pedaling.




What are the dimensions when folded?


The dimensions of the bike when folded are: width 16”, length 32”, height 27”




What are the dimensions when unfolded?


The bike dimensions in the unfolded position are: length – 5’ or 60”, handlebar width 23”, maximum seat height 42”, lowest seat height 29”, maximum handlebar height 46”, lowest handlebar height 38.5”




How many gears does the bike have?


The bike comes equipped with a six speed Shimano gear set that uses a twist style shifter on the handlebar




Why does the bike limit the speed?


The CS-240 comes pre-programmed to a maximum speed of 12 mph, and the CS-260 is programmed to a maximum speed of 15 mph to comply with most local traffic ordinances.




Does the bike come with a manual?


Yes, the bike comes with a full-color manual that walks you through the unboxing, initial set-up, and basic maintenance. The manual also contains a QR code that can be scanned to visit links with updated information, and helpful tips and tricks.




What size are the wheels?


The wheels are 20 inches in diameter. These compact but durable wheels allow for easy storage and transport while keeping the bike lightweight.




Is this bike street legal in NYC?


The Commuter Series electric bikes are considered “pedal assisted” with a top speed of less than 20 mph. New York City has some of the strictest laws in the country regarding electric powered vehicles and their different classifications. These rules and regulations are constantly evolving. We encourage all of our customers to research their local, city, and state traffic laws and ordinances regarding electric bikes prior to riding on public roads.




What kind of warranty does the bike have?


The warranty is as follows: Frame and fork – 2 years, Electric motor – 2 years, Controller – 1 year, Battery – 1 year. Normal wear and tear parts such as tubes, tires, reflectors, brake pads, etc do not have a warranty.




Does the bike have a twist throttle?


The bike comes equipped with a thumb-paddle style throttle located under the display. Simply press forward to engage the throttle feature and let go to disengage.




Can the bike take off without me pedaling?


No, there are several safety features built into this bike to prevent incidents like this. The rider must keep the throttle pressed forward to engage the full automatic mode. When the throttle is released the motor disengages. The pedals need to be rotated manually to begin moving forward before the throttle will engage the full automatic mode. Similarly, when the brakes are applied the motor disengages.




How does the full assist mode work?


The Commuter Series bikes have a thumb-paddle style throttle conveniently located beneath the display. The throttle feature allows the bike to be ridden without pedaling. The rider must keep the throttle pressed forward to engage the full automatic mode. When the throttle is released the motor disengages. The pedals need to be rotated manually to begin moving forward before the throttle will engage the full automatic mode. Similarly, when the brakes are applied the motor disengages.




Can I install a rear cargo rack that can support more weight?


The rear carrier rack on the Commuter Series bike is designed to support a maximum of 35 lbs. safely.




What is the spare bracket in the box?


The spare bracket included in the box is for the rear fender should you choose to remove the rear carrying rack.




Can this bike be shipped to Canada?


We do not currently offer international shipping.




Should the bike be stored indoors?


Bicycles tend to last longer when they are stored inside. When constantly exposed to the elements, the life expectancy of the bicycle’s electrical system, chain, braking system, and paint finish all greatly diminish. Similarly, bicycles ridden in wet and dirty conditions will require more cleaning and service to properly maintain.




Can I store the bike outdoors?


Bicycles tend to last longer when they are stored inside. When constantly exposed to the elements, the life expectancy of the bicycle’s electrical system, chain, braking system, and paint finish all greatly diminish. Similarly, bicycles ridden in wet and dirty conditions will require more cleaning and service to properly maintain.





Display Function

How do you turn on the backlight for the display?


The backlight for the display can be turned on by holding the minus ( - ) button for three seconds.




How do you change the display from miles per hour (mph) to kilometers per hour (km/h)?


The display on the CS-240 is programmed to read kilometers per hour and can’t be changed. The display on the CS-260 is programmed to read miles per hour and also can’t be changed.




Why does the display show “20” when I turn it on?


This indicates the wheel size that the bike’s controller is powering.




What is the difference between a LED and an LCD display for eBikes?


LCD displays are much more user friendly than their LED counterparts. The display for the CS-240 and CS-260 shows your current speed, a trip odometer, as well as a total distance odometer for the bike. Our display also has a backlight for riding in low-light conditions. The display is an integral part of the eBike experience that allows the rider to continually monitor the battery status and speed on the go.




What does the display show?


The display shows the current speed, battery level, trip odometer, level of pedal assist, and total odometer for the bike. The display has a backlight that can be turned on for better viewing in low light conditions.





Electric Function

How many miles can you travel on a fully charged battery with pedal assist?


There are several variables that can affect the total range on a fully charged battery. Rider weight, level of selected pedal assist (1-5), as well as the terrain type (including steep hills) will all affect the range. On average, you can expect to travel 30 to 40 miles or more on a full charge using pedal assist.




Can the battery be removed?


Yes, the battery can be removed using the keys included with the bike. With the bike folded at the hinge, simply insert the key and rotate 45 degrees to unlock, then the battery will slide out.




Can the battery be charged while it’s removed from the bike?


Yes, the battery can be removed and charged separately from the bike. The battery can be removed using the including keys and taken inside for charging.




How much does a replacement battery cost?


A replacement battery for both the CS-240 and CS-260 costs $159 including shipping.




How many times can the battery be charged before having to replace it?


The lifespan of a lithium-ion battery varies based on charging habits. Proper charging habits include fully discharging the battery before recharging and disconnecting the charger right away once the battery is fully charged. You can expect approximately 350 charging cycles from the CS-240 battery when properly charged and maintained. The "power loss curve" affects all rechargeable batteries and is a gradual curve downwards after the expected amount of charging cycles. During the first 350 charging cycles a single charge may last 3 days or 40 miles, but over time it may drop to 80%, then 70%, and so on until the battery must be charged too frequently to use.




Are extra batteries available for purchase?


Yes, additional batteries are available for purchase on our website.




How long does one charge last?


There are several variables that can affect the total range on a fully charged battery. Rider weight, level of selected pedal assist (1-5), as well as the terrain type (including steep hills) will all affect the range. On average, you can expect to travel 30 to 40 miles or more on a full charge using pedal assist.




Is the battery waterproof?


The bike’s internal electrical components are sealed with a rubber gasket to keep water out. While neither the battery nor the bike are “submersible,” they are protected against normal rain and wet riding conditions.




Does the battery have a security feature?


Yes, the battery is locked into place within the frame using a key lock. Each bike comes with two keys.




Does the battery lock in place?


Yes. When the bike is folded, the included keys can be used to lock and unlock the battery into the frame.




What are the keys for?


The keys included with the bike are for locking and unlocking the battery into the frame. The keys are not used for starting the bike.





Product Manuals

CS-240/260 Manuals

Commuter Series Manual

Totem General eBike Owners Manual

Understanding your Battery

Safety

Lithium-ion batteries have a high energy content when charged. The contents of these cells can be flammable in the right conditions. These batteries should always be handled and stored carefully. Temperatures below 15° F and above 140° F should be avoided. Avoid mechanical stresses such as dropping your battery on hard surfaces. Avoid coming in contact with moisture; always remove the battery prior to washing your bike. Note: The CS models are protected from normal wet riding conditions by a rubber gasket. NEVER open the battery’s black plastic housing. Failure to do so will void any warranty, implied or otherwise.

Charging

The 36V lithium-ion battery included with your new bike ships partially charged.
Batteries should be charged in a dry location at room temperature. The best charging practice is to fully discharge the battery, then fully charge it. The charger is equipped with over-current protection for safety. The LED light on the charger is red during charging and green when fully charged. Once the battery is fully charged it should be removed from the charger. Never leave a battery connected to a charger for long period of time unattended. Charging time depends on the battery capacity, but typically can be charged from zero to 100% in 6 hours.

Distance

There are many variables that can affect the total range on a fully charged battery. Environmental factors that affect distance are road surface type, terrain type (including steep hills), frequent stopping and starting, temperature, and wind. Rider variables including total weight and riding posture will affect the range. Bike factors such as tire tread, gear shifting, and the level of selected pedal assist will all influence the total range. On average, you can expect to travel 40 miles or more on a fully charged battery using pedal assist.

Lifespan

The "power loss curve" for lithium-ion batteries is a depiction of how the battery loses its full potential over its lifetime. This is a gradual curve downward caused by many variables such as charging habits, work load, temperature, and age. During the initial 500 charges a single charge may last 4 days or 40 miles. Over time, it may drop to 80% of the original potential, then 70%, and so on until the battery must be charged too frequently to use. Near the end of the usable life of the battery, a typical 6 hour charge may only result in a 10 mile range. Lithium-ion batteries degrade over time, even if you don’t use them.

Storage & Transport

Optimal storage locations are dry, well-ventilated areas with smoke detectors. NEVER store your battery near heat sources or flammable materials. Avoid storing the battery inside the bike in direct sunlight. For long periods of storage, the battery should have a 50% charge. Prolonged storage in a fully charged or discharged state will decrease the life of the battery. We recommend that the battery be removed from the bike for transport.

Replacement

Additional batteries and chargers for both the CS-240 and CS-260 are available for purchase on our website at www.totemusa.com  Batteries that can no longer be used should be properly disposed of at a recycling facility.

Helpful Resources

Our friends at Park Tool have created an amazing line-up of instructional videos addressing the most common bike maintenance procedures. We highly recommend their tools and accessories. Please subscribe to their channel for more great content!
